Nano-N3261

10G SFP+ fanless firewall with Intel 12th generation, 4x 2.5G LAN, DDR5

Nano-N3261 - 10G SFP+ fanless firewall with Intel 12th generation, 4x 2.5G LAN, DDR5 | IWILL UK
Network Security

Features

  • Intel Core i5-1235U / i7-1255U (10 cores, 12 threads)
  • 2x 10GbE SFP+ (Intel 82599)
  • 4x Intel i226 2.5GbE LAN
  • DDR5 4800MHz up to 64GB (2x SODIMM)
  • Fanless design
  • RJ45 console port
EmailWhatsApp
3 Years
Warranty
Fast
Delivery
Support
In English

Technical Specifications

Processor
Intel Core i5-1235U / i7-1255U (10 cores, 12 threads, up to 4.7GHz)
Memory
2x DDR5 4800MHz SODIMM, up to 64GB
Network
4x Intel i226 2.5GbE + 2x 10GbE SFP+ (Intel 82599)
Display
1x HDMI + 1x DisplayPort + 1x USB-C (video)
Storage
1x M.2 2280 + 1x 2.5" HDD/SSD
I/O
2x USB 2.0, 2x USB 3.2, 1x RJ45 Console
Dimensions
170 × 140 × 58mm
Features
Intel vPro (LAN1), PXE, Wake-on-LAN, Watchdog

Expansion & Connectivity

1x M.2 2280
1x 2.5" HDD/SSD

Operating Environment

Operating Temperature-10°C to 60°C
Storage Temperature-20°C to 70°C
Humidity5% - 95% non-condensing

Supported OS

pfSenseOPNsenseLinux (Ubuntu/Debian)Windows 10/11

Applications

Enterprise FirewallSD-WAN GatewayISP Edge SecurityData Center Protection

Description

Nano-N3261 is a compact fanless firewall appliance with Intel Core, 12th generation, 4x 2.5GbE LAN and 2x 10G SFP+ ports for high-performance network security in enterprise and ISP environments.
